- Width:
- 7.50 (in)
- Height:
- 4.75 (in)
- Depth:
- 5.00 (in)
Warranty Information
Warranty fulfilled by Antigravity BatteriesProduct Details
The all-new Antigravity ATZ-10-HD is a heavy-duty, high-capacity upgrade to our popular ATZ-10 RS battery. It features our innovative RE-START technology (built-in jump-starting) and includes a 50% larger lithium battery, offering 9Ah compared to the standard ATZ-10’s 6.1Ah. The ATZ-10-HD delivers the highest lithium capacity available in its size class. It is a direct replacement for the widely used OEM YTZ10S lead-acid battery commonly found in many adventure bikes, sport bikes, and various motorcycles and ATVs.
Features:
-
Standard YTZ10 case size: 5.9 x 3.46 x 3.62 inches (L × W × H)
-
525 cranking amps
-
18 Amp Hours (PbEq) / 9Ah actual / 115Wh
-
50% larger capacity than the standard Antigravity ATZ-10
-
Up to twice the capacity of competing models that use 4–5Ah batteries
-
Weight: 3.15 lbs
-
Enhanced safety with a full BMS and LiFePO4 lithium chemistry
-
Fits up to 12 OEM battery sizes (see list below)
-
Mountable in any orientation
-
Not intended for automotive use
Fitment:
- 690/701 (YTZ10S): Exact dimensional replacement
- 990/950/1190-1290 Adv/Rc8 (YTZ14S): This battery has a nearly identical footprint, but is about 3/4" (20mm) shorter in height.
- Super Duke 1290 R/GT: The battery on this page fits perfectly in width and length, but is 2" (50mm) shorter in height. This extra space can be filled with a Dynojet Powercommander V and Ignition Module nicely. The AG-AT12BS-RS battery fits perfectly in width, but is 3/4" (20mm) thinner front to back and about 3/8" (10mm) shorter from top to bottom than the battery on this page. Also perfect for extra storage of Dynojet products or anything else that may fit.
- RC390: Slightly shorter in height but the rubber band compensates perfectly. Side to side, front to back is identical so it fits in very well on this bike.
Stock vs Antigravity Comparisons:
- Stock Yuasa YTZ14S weight: 8.6 lbs (3.9 kg)
- Stock Yuasa YTZ10S weight 6.8 lbs (3.08kg)
- Antigravity ATZ10 weight: 2.3 lbs (1 kg) -4.5 - 6.3 lbs!
- Stock YTZ14S size: 6 x 3.437 x 4.375 (152 x 87 x 111mm)
- Stock YTZ10S size: 5.9 x 3.4 x 3.65 in (150 x 86 x 93mm)
- Antigravity ATZ10 size: 5.9 x 3.5 x 3.74 in (150x89x95mm)
- Stock YTZ14S cranking amps: 230
- Stock YTZ10S cranking amps: 190
- Antigravity ATZ10 cranking amps: 360
Technical Details:
- Shipping Weight 2.7 lbs
- Shipping Dimensions 7.5 x 4.75 x 5 in (190 x 121 x 127mm)
- Product Weight 2.3 lbs (1kg)
- Product Size 5.9 x 3.5 x 3.74 in (mm: 150 x 89 x 95mm)
- Cranking Amps 360
- Amp Hours (Pb Eq) 10
The lithium ATZ-10-HD-RS is a direct replacement for these OEM battery sizes:
- YTZ, BTZ, YTX, BTX Models
- YTZ10S
- YTZ12
- YTZ14
- BTZ10S
- BTZ12
- BTZ14
- YTX9
- YTX7A-BS
- YTX12A-BS
- BTX9
- BTX7A-BS
- BTX12A-BS
NOTE: Use only Lithium specific Motorsport Chargers to charge this battery! Do not use Lead/Acid Chargers. This item is considered hazardous material. Orders containing this product will ship ground only. This product cannot be shipped to Alaska, Hawaii, or Territories outside the United States or any International destination. If an order from any of these listed places arrives we will have to cancel this item and it will be refunded.
